Stationary Welding Fume Extractor – High-Volume Filtration with Activated Carbon
The stationary welding fume extractor FRESHWELD SM/910 is a robust and high-capacity industrial air filtration system designed for fixed installation in welding halls and production facilities. Built for continuous operation, this unit ensures safe and efficient removal of welding fumes, dust, and gaseous contaminants across large workspaces.
Thanks to its 4-stage filtration system, the SM/910 handles large air volumes with high precision. It includes a G2 mesh pre-filter, G4 coarse filter, a fine F9 or EPA E12 filter, and an activated carbon cell with 12kg of adsorbent material. This makes the unit highly effective in capturing both particles and odors.
A 1.5kW motor drives the filtration process, delivering up to 1300m³/h airflow. The unit is designed for connection to a fixed ductwork system and can serve one or more extraction points, depending on the configuration. Filter change indicators, spark protection, and electrical safety features ensure continuous, trouble-free operation.
This model is suited for industrial welding booths, robotic welding cells, and centralized extraction systems where mobility is not required.
All 8 Model Variations of the SM/910 Series
| FW Code | Arm Setup | Final Filter | Carbon Filter | Airflow | Weight |
|---|---|---|---|---|---|
| 121SM91000 | Without arm | F9 Fine Filter (25m²) | 12kg | 1000–1300 m³/h | 122kg |
| 121SM91002 | 1 x 2m | F9 Fine Filter (25m²) | 12kg | 850–1300 m³/h | 132kg |
| 121SM91003 | 1 x 3m | F9 Fine Filter (25m²) | 12kg | 850–1300 m³/h | 139kg |
| 121SM91004 | 1 x 4m | F9 Fine Filter (25m²) | 12kg | 850–1300 m³/h | 143kg |
| 122SM91000 | Without arm | E12 EPA Filter (40m²) | 12kg | 1000–1300 m³/h | 122kg |
| 122SM91002 | 1 x 2m | E12 EPA Filter (40m²) | 12kg | 850–1300 m³/h | 132kg |
| 122SM91003 | 1 x 3m | E12 EPA Filter (40m²) | 12kg | 850–1300 m³/h | 139kg |
| 122SM91004 | 1 x 4m | E12 EPA Filter (40m²) | 12kg | 850–1300 m³/h | 143kg |
Key Features at a Glance
Stationary design for fixed installations
4-stage filtration: G2, G4, F9 or E12, and 12kg activated carbon
Suitable for connection to ductwork or extraction arms (2–4m)
Quiet 72dB operation during continuous use
Airflow capacity up to 1300 m³/h (1.5kW motor)
Spark arrestor, phase protection, and reverse rotation alarm
Filter change indicators included
Ideal for robotic welding cells and fixed welding booths
Certified: EN 779, EN 1822, EN ISO, and Machinery Safety compliant
As a result, the stationary welding fume extractor delivers long-lasting protection in professional welding environments. In fact, it improves air quality and worker safety across entire production zones. Moreover, with its activated carbon stage, it removes harmful gases and odors effectively. Therefore, the SM/910 is a reliable industrial air filtration system for fixed and high-volume extraction setups.
RAM SVEIS OG BEMANNING AS is the exclusive distributor of FRESHWELD in Norway, offering local service, support, and fast delivery.
